Sentry Magnetic Trap Filter MT-5
Part #: TBD
Get Started
Request A QuoteStill Have Questions?
Contact Us
Magnetite particles can cause problems within a sampling system by jamming and plugging components. By isolating magnetite particulates, the Sentry magnetic trap protects your sampling equipment from unplanned downtime and equipment damage caused by contamination.
The magnetic trap filter uses high strength neodymium magnets in its core to attract and capture the magnetite found in systems before an issue arises. Coming in both high and low pressure models, the magnetic trap is easily adaptable to your system needs.
- The Sentry MT-5 magnetic trap captures only extrained oxide particulate and lets the remaining particulates pass. This protectts conditioning equipment and maintains sample integrity.
- The Sentry Magnetic Trap is designed to never plug and handle conditions within a power plant.
- Each magnetic trap is hydrotested to hold up within retrofits as well as new equipment.
- Select traps incorporate unique cyclonic cleaning, removing the need for tools to purge.
- Meets ASME Section VIII, Div. 1 and CRN compliance standards
Features
- Easy single-stroke cyclone flsuh requires only one operator, one turn of hte handle, and 10 to 15 seconds of flushing
- Single-stroke actuator and purge-inplace required no tools or dissasembly and prevents the intriduction of O2 into the sample stream
- Available as a stand-alone trap or as a complete assembly with all necessary components
- Hydrotested
- Designed for installation after primary cooling
| Model | Pressure Rating | Max Flow Rate | Wetted Materials |
|---|---|---|---|
| MT-1 |
316 SS, POM, polycarbonate,
glass-filled polypropylene, Buna-N |
1200 ccm | 100 PSI (6.75 bar) |
| MT-2 | 316 SS | 1200 ccm | 2500 PSI (172 bar) |
| MT-5 | 316 SS | 1200 ccm | 5000 PSI (345 bar) |
